As soon as all eight pulses are transmitted through the air, the echo pin goes high.

As a result, the transmitter circuit produces 8 pulses burst of ultrasound waves and each pulse has 40KHz frequency.

First of all, we apply 10 microseconds pulse to the Trigger pin of HC-SR04 sensor from general purpose input output pin of TM4C123 microcontroller.

Now let’s see the steps to initiate distance ranging or get echo pulse output: The width of this pulse or pulse duration can be used to measure the distance. On the other hand, an ultrasonic receiver listens to these ultrasonic sound waves and if the receiver circuit receives these ultrasonic sound waves, it produces a pulse on the output pin.

The ultrasonic transmitter circuit converts the electrical signals into 40kHz ultrasonic sound waves. As you mentioned earlier, it consists of one ultrasonic transmitter circuit and one ultrasonic receiver circuit. In this section, we will see how HC-SR04 ultrasonic sensor work. Therefore, you must connect an external 5 volt supply to power HC-SR04. Additionally, TM4C123 Tiva Launchpad does not have an onboard 5 volts signal. Note: This sensor does not work properly on a 3.3 volts power supply. Trigger pin is used to initiate the sensor to start ranging. The echo output pulse pin is used to get output from the sensor. The other two pins are Trigger and echo pin. Two of them are power supply pins such as +5V and ground.
